The Linx TT 500 is a 32mm printhead thermal transfer overprinter for coding flexible packaging at up to 150 prints per minute and line speeds to 500mm per second.

Where the TT 500 fits

It shares the TT 750's air-free motor drive and cassette ribbon system in a narrower format. If your codes are dates, lot and batch numbers rather than full ingredient panels, the 32mm head does the job without paying for print width you will not use.

Key benefits

• Operates without compressed air
• Push-button open and close cassette system for simple ribbon threading
• Clutchless bi-directional ribbon drive
• Colour touchscreen interface
• Universal bracket systems for intermittent and continuous motion packaging machinery

Specifications

• Printhead width: 32mm
• Throughput: up to 150 prints per minute
• Line speed: up to 500mm per second
• Substrates: flexible packaging, film, labels and gloss card

Ribbons we stock for it

The matching width for this printhead is our Black Wax/Resin TTO Ribbon, 33mm x 700m, wound coated side out, 24 rolls per case and made in the USA. See the full range in TTO Ribbons.

Need more print area?

For ingredient panels, logos or multi-line blocks, the Linx TT 750 takes a 53mm printhead and runs to 250 prints per minute.
